A minimalist Fast Fourier Transform library.
It achieves high performance by simple means.
The library routines compute:
- Forward and inverse complex DFT,
- Forward and inverse DFT of real data,
- Cosine and sine transforms of types 2, 3, 4
of any dimensionality and power-of-two lengths.
The library provides C and Fortran interfaces.
All transform routines take three arguments:
- input data pointer
x,
- output data pointer
y,
- auxiliary data pointer
a.
The transform routines are capable of both in-place and out-of-place
operation. In the latter case the input is left intact.
Auxiliary data contain chains of precomputed constants and temporary
memory buffers, required for a transform routine to do its job. Once
prepared, the auxiliary data can be reused as many times as needed.
Also, the same auxiliary data fit for both forward and inverse
transforms of the same kind.
These examples in C and Fortran show how the library functions are used:
#include "minfft.h"
minfft_cmpl x[N],y[N]; // input and output buffers
minfft_aux *a; // aux data
// prepare aux data
a=minfft_mkaux_dft_1d(N);
// do transforms
minfft_dft(x,y,a);
minfft_invdft(y,x,a);
// free aux data
minfft_free_aux(a);
use minfft
complex(minfft_cmpl),dimension(n) :: x,y ! input and output buffers
type(minfft_aux) :: a ! aux data
! prepare aux data
a=minfft_mkaux_dft_1d(n)
! do transforms
call minfft_dft(x,y,a)
call minfft_invdft(y,x,a)
! free aux data
call minfft_free_aux(a)
The library defines its own types for real and complex numbers, and for
auxiliary data:
| C |
Fortran |
minfft_real |
real(minfft_real) |
minfft_cmpl |
complex(minfft_cmpl) |
minfft_aux |
type(minfft_aux) |
By default, minfft_real is double. If C99 native complex is
available, then minfft_cmpl is double complex. Otherwise,
minfft_cmpl is an array of two minfft_reals. It is
binary-compatible with other known complex number types, such as MSVC
_Dcomplex or C++ complex<double>.
To build a single precision version, define the MINFFT_SINGLE macro.
Below is a list of transforms with their definitions, auxiliary data
makers, and transform routines.
For convenience, we provide aux data makers for one-, two- and
three-dimensional transforms, along with a generic any-dimensional one.
The dimensions are passed to aux maker routines in the C order (most
rapidly varying index is the last). So, when calling from Fortran,
array dimensions must be passed in the reverse order:
complex(minfft_cmpl),dimension(n1,n2,n3) :: z
a=minfft_mkaux_dft_3d(n3,n2,n1)
Auxiliary data makers return NULL if an error occured.
Our definitions of transforms, and formats of input and output data, are
fully compatible with FFTW.
minfft_aux* minfft_mkaux_dft_1d (int N);
minfft_aux* minfft_mkaux_dft_2d (int N1, int N2);
minfft_aux* minfft_mkaux_dft_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_dft (int d, int *Ns);
void minfft_dft (minfft_cmpl *x, minfft_cmpl *y, const minfft_aux *a);
minfft_aux* minfft_mkaux_dft_1d (int N);
minfft_aux* minfft_mkaux_dft_2d (int N1, int N2);
minfft_aux* minfft_mkaux_dft_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_dft (int d, int *Ns);
void minfft_invdft (minfft_cmpl *x, minfft_cmpl *y, const minfft_aux *a);
This transform returns mostly non-redundant part of the complex DFT of
real data.
For a real array of dimensions
it produces a complex array of dimensions
Note that output takes a little more space than input. For in-place
operation, make sure the data buffer is big enough to contain output.
minfft_aux* minfft_mkaux_realdft_1d (int N);
minfft_aux* minfft_mkaux_realdft_2d (int N1, int N2);
minfft_aux* minfft_mkaux_realdft_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_realdft (int d, int *Ns);
void minfft_realdft (minfft_real *x, minfft_cmpl *z, const minfft_aux *a);
This is the inversion of the real DFT.
It takes a complex array of dimensions
and returns a real array of dimensions
NB: Multidimensional inverse real DFT does not preserve input.
minfft_aux* minfft_mkaux_realdft_1d (int N);
minfft_aux* minfft_mkaux_realdft_2d (int N1, int N2);
minfft_aux* minfft_mkaux_realdft_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_realdft (int d, int *Ns);
void minfft_invrealdft (minfft_cmpl *z, minfft_real *y, const minfft_aux *a);
minfft_aux* minfft_mkaux_t2t3_1d (int N);
minfft_aux* minfft_mkaux_t2t3_2d (int N1, int N2);
minfft_aux* minfft_mkaux_t2t3_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_t2t3 (int d, int *Ns);
void minfft_dct2 (minfft_real *x, minfft_real *y, const minfft_aux *a);
minfft_aux* minfft_mkaux_t2t3_1d (int N);
minfft_aux* minfft_mkaux_t2t3_2d (int N1, int N2);
minfft_aux* minfft_mkaux_t2t3_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_t2t3 (int d, int *Ns);
void minfft_dst2 (minfft_real *x, minfft_real *y, const minfft_aux *a);
minfft_aux* minfft_mkaux_t2t3_1d (int N);
minfft_aux* minfft_mkaux_t2t3_2d (int N1, int N2);
minfft_aux* minfft_mkaux_t2t3_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_t2t3 (int d, int *Ns);
void minfft_dct3 (minfft_real *x, minfft_real *y, const minfft_aux *a);
minfft_aux* minfft_mkaux_t2t3_1d (int N);
minfft_aux* minfft_mkaux_t2t3_2d (int N1, int N2);
minfft_aux* minfft_mkaux_t2t3_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_t2t3 (int d, int *Ns);
void minfft_dst3 (minfft_real *x, minfft_real *y, const minfft_aux *a);
minfft_aux* minfft_mkaux_t4_1d (int N);
minfft_aux* minfft_mkaux_t4_2d (int N1, int N2);
minfft_aux* minfft_mkaux_t4_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_t4 (int d, int *Ns);
void minfft_dct4 (minfft_real *x, minfft_real *y, const minfft_aux *a);
minfft_aux* minfft_mkaux_t4_1d (int N);
minfft_aux* minfft_mkaux_t4_2d (int N1, int N2);
minfft_aux* minfft_mkaux_t4_3d (int N1, int N2, int N3);
minfft_aux* minfft_mkaux_t4 (int d, int *Ns);
void minfft_dst4 (minfft_real *x, minfft_real *y, const minfft_aux *a);
If not needed anymore, the memory consumed by the auxiliary data can
be freed by the minfft_free_aux() routine:
void minfft_free_aux (minfft_aux *a);
Our library does not try to save memory, and allocates temporary buffers
wherever it benefits performance.
The amounts of memory allocated for the auxiliary data of the
one-dimensional transforms are given below:
| Transform |
Auxiliary data size |
Complex DFT of length N |
2N complex numbers |
Real DFT of length N |
3.5N real numbers |
Type-2 or Type-3 transform of length N |
5.5N real numbers |
Type-4 transform of length N |
6N real numbers |
Multi-dimensional transforms use a temporary buffer of the same size as
the input data. This value is the dominant term in their auxiliary data
size.
The complex DFT is computed by a split-radix (2/4), decimation in
frequency, explicitly recursive fast Fourier transform. This method
achieves a remarkable balance between performance and simplicity, and it
behaves particularly cache-friendly, since it refers mostly to adjacent
memory locations.
The real transforms are reduced eventually to a half-length complex
transform.
For each transform, we first implement its one-dimensional,
out-of-place, input-preserving, sequential input, strided output
routine. This allows us to compute a multi-dimensional transform by
repeated application of its one-dimensional routine along each
dimension.
Below are the plots of speed and accuracy of our library, compared
with the libraries of similar design — KissFFT and PocketFFT.
Performance of a highly optimized machine-specific version of the FFTW
library is also shown for reference.
C89, Fortran 2003.
MIT.
